Stepless speed without the hydrostatic fuel penalty
The YT347 is built around the i-HMT, Yanmar's Integrated Hydro Mechanical Transmission, and it's the reason to look at this tractor over anything else in the lineup. A conventional hydrostatic transmission is easy to drive but loses power to fluid. A gear drive is efficient but makes you shift. The i-HMT splits power between a mechanical path and a hydraulic one, so you get stepless main shift with a high power transfer ratio and lower fuel consumption.
What that means in the seat: set a speed and it holds, clutch-free shifting, and you can stop the vehicle without touching a clutch. The engine is a 46-horsepower 4TNV88C four-cylinder Tier 4 diesel producing 39.5 HP at the PTO at working speed.
Electronic controls that earn their keep
The YT347 carries anti-stall, which backs off ground speed instead of killing the engine when a load spikes, and electronic cruise control for repeatable operating speed across a field. An A/B mode lets you store engine and vehicle speed settings and switch between them, and a throttle boost button gives you a burst without resetting your throttle. A large LCD display ties the controls together, and a 12V outlet and rear remote are standard.
The loader
The YL610 lifts 2,500 lb at the pivot pin to a maximum of 113 inches, with 3,969 lb of breakout force at the pins and 3,047 lb measured 500 mm forward. The 72-inch bucket holds 10.9 cubic feet, dump clearance is 88 inches, and a grille guard is standard. Loader control is a 4-way valve with joystick, and a third-function valve is available.
Hitch and hydraulics
The Category 1 three-point hitch lifts 3,307 lb standard and 2,756 lb at 24 inches behind the lift point, which is more than the gear-drive YM347 manages. Implement flow is 10.1 GPM with 5.7 GPM to fully hydraulic power steering. Travel is 0 to 18 mph in both directions across three variable-speed ranges.
Yanmar YT347 specifications
- Engine: Yanmar 4TNV88C Tier 4, 4-cylinder liquid-cooled diesel, 133.5 cu in
- Power: 46 HP gross at 2,800 RPM, 39.5 HP PTO at working speed
- Transmission: i-HMT, 3 variable-speed ranges, power-shift reverser
- Travel speed: 0 to 18 mph forward and reverse
- PTO: Rear 540 RPM
- Three-point hitch: Category 1, 3,307 lb standard, 2,756 lb at 24 in
- Loader (YL610): 2,500 lb lift at pivot pin, 113 in lift height, 72 in bucket, 10.9 cu ft
- Hydraulics: 10.1 GPM implement, 5.7 GPM steering, 4-way loader valve standard
- Electronics: Anti-stall, cruise control, auto throttle, A/B mode, throttle boost, LCD display
- Fuel capacity: 12.7 gallons
- Ground clearance: 12.8 in with R4 tires. Wheelbase: 75.9 in
- Weight: 3,880 lb with ROPS, R4 tires, full fluids
- Standard: Rear remote, 12V outlet, grille guard
What will it cost per month?
The payment calculator on this page gives a quick monthly estimate, and building yours shows live payment options across terms and down payments. Submitting sends a quote request, and we'll follow up with your pricing. Payment figures are estimates, subject to credit approval.
Buying a YT347 in central Pennsylvania
Green Spring Tractor is a Yanmar dealer at 846 Greenspring Road in Newville, Pennsylvania, serving Cumberland County and the surrounding area. Every new Yanmar tractor is assembled in Adairsville, Georgia, with parts shipped from that same facility. Coverage runs 24 months or 2,000 hours on the machine and 10 years or 3,000 hours on the powertrain for non-commercial use.
Call 717-776-4040 and ask to drive one. The i-HMT is difficult to describe and obvious in the first thirty seconds behind the wheel.
Already own one? Browse genuine parts for the Yanmar YT347: filters, belts, and maintenance kits cross-referenced to your model.
Specifications
| Tire Type | R1 Ag, R3 Turf, R4 Industrial |
