A subcompact tractor that does real loader work
The Yanmar SA325 is built for the property owner who has outgrown a riding mower but doesn't want a farm tractor taking up the shed. Its 23.9-horsepower 3TNV80F diesel is a three-cylinder, liquid-cooled 1.27-liter engine making 45.7 ft-lbs of torque, which is what actually matters when you're curling a full bucket of wet gravel uphill.
At 8.5 feet of turning radius it works between buildings and along fence lines where a bigger machine needs three attempts.
How much can the SA325 lift?
The YL210 curved-boom loader lifts 1,200 lb at the pivot pin with 2,090 lb of breakout force, reaching 79 inches at maximum height. That's enough to clear the wall of a pickup bed. It quick-attaches without tools, so swapping between loader work and a rear implement is a two-minute job.
Out back, the Limited Category 1 three-point hitch lifts 1,209 lb measured 24 inches behind the lift point, and the independent PTO puts out 18.1 HP at 554 RPM, with a mid-PTO at 2,057 RPM for a belly mower.
Twin-pedal hydrostatic drive
Two side-by-side pedals switch between forward and reverse without your hand leaving the wheel. In loader work, where you change direction every few seconds, that's the single biggest quality-of-life difference on the machine. Dual ranges give you 0 to 5.9 mph for precise grading and up to 12.3 mph to cross the property.
Selectable 4WD, wet-disk brakes, and hydrostatic power steering are standard, as are two rear remote valves and a 12V outlet. Hydraulic implements are ready to run the day you take delivery.
Choosing your tires
The SA325 is available with R3 turf tires, which spread the load and protect established lawn, or R4 industrial tires, which give you a tougher sidewall and better grip on gravel, dirt, and construction debris. Turf if you're mowing finished ground. Industrial if you're moving material. Not sure? Call us. It's a five-minute conversation, and the wrong answer is annoying for years.
Yanmar SA325 specifications
- Engine: Yanmar 3TNV80F, 3-cylinder liquid-cooled diesel, 77.2 cu in (1.27 L)
- Power: 23.9 HP gross, 21.7 HP net at 3,200 RPM, 45.7 ft-lbs torque
- Transmission: Hydrostatic, dual range, twin-pedal, selectable 4WD
- PTO: 18.1 HP independent, rear 554 RPM, mid 2,057 RPM
- Three-point hitch: Limited Category 1, 1,209 lb at 24 in behind lift point
- Loader (YL210): 1,200 lb lift, 2,090 lb breakout, 79 in lift height, 53 in bucket
- Hydraulics: 4.3 GPM implement pump, 2,429 PSI, two rear remotes standard
- Fuel capacity: 6.1 gallons. Turning radius: 8.5 ft
- Weight: 1,715 lb with ROPS and R4 tires
- Ground clearance: 8.5 in with R4 tires
- Also fits: B65 backhoe, M60 60-inch mid-mount mower, front blade, snow blower
What will it cost per month?
The payment calculator on this page gives a quick monthly estimate, and building yours shows live payment options across terms and down payments. Submitting sends a quote request, and we'll follow up with your pricing. Payment figures are estimates, subject to credit approval.
Buying an SA325 in central Pennsylvania
Green Spring Tractor is a Yanmar dealer at 846 Greenspring Road in Newville, Pennsylvania, serving Cumberland County and the surrounding area. Every new Yanmar tractor is assembled in Adairsville, Georgia, with parts shipped from that same facility. Coverage runs 24 months or 2,000 hours on the machine and 10 years or 3,000 hours on the powertrain for non-commercial use.
Call 717-776-4040 and tell us what your property throws at you. We'll tell you honestly whether the SA325 is the right size or whether you want the SA425 with its taller tire package.
Already own one? Browse genuine parts for the Yanmar SA325: filters, belts, blades, and maintenance kits, all cross-referenced to your model.
Specifications
| Tire Type | R3 Turf, R4 Industrial |
